| Capacity: | 300W, 500W, 1000W | Voltage Range: | 0.005V～30.00V, 0.005V~50.000V, 0.0005V~300.00V |
|---|---|---|---|
| Current Range: | 0.005A～10.00A, 0.005A~10.00A, 0.005A~5.00000A | Warranty: | 1 Year |
| Shippment: | By Express | ||
| High Light: | ac dc power meter,linear power supply |
||
High Accuracy 30V/10A 300W DC Power Source
CC&CV DC Power Supply
PG series power supply is special designed for standard lightsoure, it is a high stable and linear power source, with the features of high stability, accuracy, and current adjustable.
| Model | 3010 | 5010 | 30005 | ||
| Input Voltage | AC220V±3% 50/60Hz | ||||
| Output voltage(DC) | 0.005V～30.00V | 0.005V~50.000V | 0.0005V~300.00V | ||
| Output Current(DC) | 0.005A～10.00A | 0.005A~10.00A | 0.005A~5.00000A | ||
| Voltage drift | (±0.01%reading+1mV)/3mins | ||||
| Current drift | (±0.01%reading+1mA)/3mins | ||||
| Voltage accuracy | ±(0.02%reading+0.01%) | ||||
| Current voltage | ±(0.02%reading+0.01%) | ||||
| Max output power | 300W | 500W | 1500W | ||
