Rain Test Chamber JISD0203

Environment Testing Equipment
January 22, 2025
Category Connection: Environment Test Equipment
Chat Now Contact Us
Tags:
#temperature humidity test chamber #environmental test chamber #environmental testing equipment
Brief: This video showcases the JISD0203 Water Ingress Protection Environment Testing Machine, demonstrating its compliance with JISD0203 standards for spray and jet tests on auto parts. Viewers will see the machine's operation, including its 7-inch touch screen control, transparent viewing window, and adjustable turntable settings.
Related Product Features:
  • Compliant with JISD0203 standards for R1/R2 spray tests and S1/S2 jet tests.
  • High-quality steel plate shell with SUS304# stainless steel inner chamber and turntable.
  • Box-type structure with a transparent viewing window and LED light for clear sample observation.
  • Manual control of flow and pressure for JIS nozzles on the panel.
  • Turntable speed and angle adjustable via LCD screen.
  • Equipped with Taiwan Weilun 7-inch screen and Panasonic PLC for precise control.
  • Capable of performing R1, R2, S1, and S2 tests individually or simultaneously.
  • Includes safety features like leakage protection, water shortage protection, and short circuit protection.
FAQs:
  • What standards does the JISD0203 testing machine comply with?
    The machine complies with JISD0203 standards for spray tests (R1 and R2) and jet tests (S1 and S2) on auto parts.
  • What materials are used in the construction of the testing machine?
    The shell is made of high-quality steel plate, while the inner chamber and turntable are constructed from SUS304# stainless steel.
  • How is the testing machine controlled?
    The machine is controlled via a 7-inch touch screen and Panasonic PLC, allowing users to adjust settings like turntable speed, angle, and test duration.
  • What safety features does the machine include?
    The machine includes safety features such as leakage protection, water shortage protection, and short circuit protection to ensure safe operation.
