Impact Pistol for Verifying the Mechanical Strength of Enamels Articles

Mechanical Impact Testing Equipment
December 02, 2025
Chat Now Contact Us
Brief: Watch our dynamic demonstration of the ISO4532 Compliant Pistol Test Apparatus in action. This video provides a clear walkthrough of how to verify the mechanical strength of enamelled articles using impact force, showcasing the device's adjustable settings and practical application on various sample surfaces.
Related Product Features:
  • Compliant with ISO4532 standard for testing enamelled articles against impact.
  • Features a continuously adjustable impact force range from 0 to 90 N/cm.
  • Equipped with a striking bolt that has a precise 5mm steel ball tip.
  • Includes a spring load mechanism and trigger for controlled impact testing.
  • Comes with a versatile tripod stand for stable testing on uneven surfaces and edges.
  • Offers a minimum force scale adjustment precision of 2 N/cm for accurate testing.
  • Designed as a completely mechanical instrument for reliable and straightforward operation.
  • Enables determination of the resistance of enamelled articles to mechanical impact.
Faqs:
  • What standard does this pistol test apparatus comply with?
    This pistol test apparatus is designed and compliant with the ISO4532 standard, which specifies the method for determining the resistance of enamelled articles to impact.
  • What is the impact force range of this testing device?
    The device offers a continuously adjustable impact force range from 0 to 90 N/cm, with a minimum adjustable precision of 2 N/cm, allowing for precise control during testing.
  • Can this apparatus test enamelled articles on uneven surfaces?
    Yes, the specially designed tripod stand included with the apparatus allows for stable and accurate testing on both uneven sample surfaces and sample edges, ensuring versatile application.
