Pendulum Hammer Impact Test Apparatus with 0~90 Degree Impact Angle for IK07 to IK11 Tests and Steel Striking Element

Pendulum Hammer Impact Test Apparatus with 0~90 Degree Impact Angle for IK07 to IK11 Tests and Steel Striking Element
Pendulum Hammer Impact Test Apparatus with 0~90 Degree Impact Angle for IK07 to IK11 Tests and Steel Striking Element
video play

Large Image :  Pendulum Hammer Impact Test Apparatus with 0~90 Degree Impact Angle for IK07 to IK11 Tests and Steel Striking Element

Product Details:
Place of Origin: China
Brand Name: Pego Electronics
Certification: Third-Lab Calibration Certificate
Model Number: PG-PD50
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: carton
Delivery Time: 15 business days
Payment Terms: T/T,PayPal
Contact Now
Detailed Product Description
Reference Standard: IEC62262, IEC60068-2-75 Material Of The Striking Element: Steel
Material Of Rig: Aluminum Alloy Impact Energies: IK07 (2J), IK08 (5J), IK09 (10J), IK10 (20J), IK11(50J)
Release Mode: Manual Release Impact Angle: 0~90 Degree
Highlight:

0~90 Degree Impact Angle Pendulum Hammer

,

IK07 to IK11 Tests Impact Test Apparatus

,

Steel Striking Element Mechanical Impact Tester

2J to 50J Pendulum Hammer Mechanical Impact Test Apparatus IEC62262
The pendulum hammer mechanical impact test apparatus meets the test requirements of IEC60068-2-75 and IEC62262 standards. This robust equipment consists of striking elements, swing pipes, and a test rig designed for precise mechanical impact testing.
Key Features
  • Constructed with steel striking elements and aluminum alloy test rig
  • Features 1000mm swing pipes with configurable masses
  • Adjustable falling height for performing IK07 to IK11 tests
  • Includes dial indicator for precise height measurement
  • Mobile design with four wheels for easy positioning
  • Ideal for testing impact points on vertical surfaces without overhangs
Technical Specifications
Swing Pipe Steel pipe 1 (Length: 1000mm, outer diameter: 15.9mm, thickness: 1.5mm) for energies exceeding 2J
Steel pipe 2 (Length: 1000mm, outer diameter: 9.0mm, thickness: 0.5mm) for energies not exceeding 2J
Impact angle 0~90°
Lifting stroke 200-1200mm
Impact hammers Striking elements: 2J for IK07 test, 5J for IK08 test, 10J for IK09 test, 20J for IK10 test, 50J for IK11 tests
Material: steel
Equivalent mass of hammers ≤1J: 0.2KG, IK07: 0.5KG, IK08: 1.7KG, IK09: 5KG, IK10: 5KG, IK11: 10KG
Hammer release method Manual release
Mounting Fixtures Flat mounting plate for IK07 to IK10 tests, adjustable angle 0-90°, equipped with M6 screw holes
Impact Test Parameters
Model (energy) 2J 5J 10J 20J 50J
Equivalent mass/kg 0.5 1.7 5 5 10
Height of fall±1%/mm 400 300 200 400 500
Frequently Asked Questions
How to know the falling height?

The equipment includes a dial to indicate the falling height. Simply pull the swing pipe to the corresponding height and release it.

Pendulum Hammer Impact Test Apparatus with 0~90 Degree Impact Angle for IK07 to IK11 Tests and Steel Striking Element 0
How to position the sample?

The equipment includes a flat mounting fixture with M6 screw holes. Lighter samples can be placed on the mounting plate, which can be tilted 0-90°. For heavier or larger samples, they can be placed directly on the ground.

Pendulum Hammer Impact Test Apparatus with 0~90 Degree Impact Angle for IK07 to IK11 Tests and Steel Striking Element 1
How to avoid secondary impacts?

After the initial impact, grasp the striking element by hand to retain the hammer, being careful to avoid the arm to prevent distortion. While electronic brake devices are available, they carry a risk of swing arm deformation.

Will you provide installation service?

The equipment ships fully assembled and requires no installation service.
