IEC60068-2-3 Compliant Temperature Impact Test Chamber with TEMI880N Controller

IEC60068-2-3 Compliant Temperature Impact Test Chamber with TEMI880N Controller
IEC60068-2-3 Compliant Temperature Impact Test Chamber with TEMI880N Controller

Large Image :  IEC60068-2-3 Compliant Temperature Impact Test Chamber with TEMI880N Controller

Product Details:
Place of Origin: China
Brand Name: PEGO GROUP
Certification: CE Certificate
Model Number: PG-TSC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD10000~USD15000
Packaging Details: woodencase
Delivery Time: 30 working days
Payment Terms: T/T,Western Union,MoneyGram
Contact Now
Detailed Product Description
Standard: MIL STD，GB，JIS，JEDEC，IEC60068-2-3 Type: Three Box Type
Thermal Shock Range: -40℃～ +120℃ Material: Stainless Steel
Size: 60L, 80L, 100L, 120L (optional) Warranty: 12 Months
Working Power: AC380V, 50HZ Control System: TEMI880N+LCD Touch Screen
Highlight:

IEC60068-2-3 temperature impact test chamber

,

temperature test chamber with TEMI880N controller

,

environment test equipment with warranty

IEC60068-2-3 Compliant Temperature Impact Test Chamber with TEMI880N Controller
The PG-TSC three-box thermal shock chamber is engineered specifically for evaluating material performance under rapid temperature transitions. This environmental test equipment operates across a -40℃ to +120℃ temperature cycling range, utilizing a dual-chamber architecture that separates high and low temperature zones from the test space.
Technical Specifications
Parameter Specification
Temperature Cycling Range -40℃ ~ +120℃
High Temperature Zone +80℃ ~ +200℃
Low Temperature Zone -10℃ ~ -60℃
Temperature Accuracy ±2℃
Temperature Resolution 0.01℃
Rising Time (Hot Space, RT~150℃) < 40 mins
Rising Time (Cold Space, RT~-40℃) < 50 mins
Recovery Time (-40℃~+120℃) 3 ~ 5 mins
Interior Volume Options 60L / 80L / 100L / 150L
Working Power AC380V, 50HZ (3-phase 5-wire)
Controller TEMI880N + LCD Touch Screen
Applicable Standards IEC60068-2-3, MIL STD, GB, JIS, JEDEC
Warranty 12 Months
Key Features & Benefits
  • Three-Box Structure: Maintains physical separation of high and low temperature reservoirs from test chamber, eliminating mechanical specimen movement during temperature transitions
  • Rapid Temperature Recovery: Achieves target temperature transitions between -40℃ and +120℃ within 3-5 minutes, reducing total cycle time for high-volume testing
  • Multiple Volume Options: Available in 60L, 80L, 100L, and 150L configurations to match specific specimen dimensions and testing requirements
  • Advanced Control System: TEMI880N controller with LCD touch screen interface for precise test programming and real-time monitoring
Applications
This environmental test equipment is designed for manufacturers and testing laboratories working with international standards including IEC60068-2-3, MIL STD, GB/T2423, JIS C 60068, and JEDEC standards. Typical applications include thermal fatigue testing of solder joints in electronic assemblies, evaluation of plastic component behavior under repeated thermal expansion and contraction, assessment of metal substrate integrity after exposure to rapid temperature swings, and quality screening of finished products in batch production environments.
Technical Operation
The PG-TSC utilizes a closed-loop air circulation system in both high and low temperature chambers. Each zone features independent heater, evaporator, fan, and duct configurations, maintaining temperature states separately and switching into the test space on demand. The TEMI880N controller compares temperature signals from sensing elements against programmed setpoints and drives solid-state relays to adjust heater output with PID precision. The test chamber employs forced axial flow with scattering-type loop wind design to improve temperature uniformity and reduce fluctuation during steady-state hold periods.
Chamber construction incorporates high-density glass wool thermal insulation and high-strength PU foam to minimize heat exchange. The stainless steel cabinet provides corrosion resistance from condensation during humidity-temperature combined cycle tests.
