IEC60335-2-7 Door Interlock Endurance Testing Machine For Washing Machine

IEC60335-2-7 Door Interlock Endurance Testing Machine For Washing Machine
IEC60335-2-7 Door Interlock Endurance Testing Machine For Washing Machine IEC60335-2-7 Door Interlock Endurance Testing Machine For Washing Machine

Large Image :  IEC60335-2-7 Door Interlock Endurance Testing Machine For Washing Machine

Product Details:
Place of Origin: China
Brand Name: PEGO Group
Certification: Third-Lab Calibration Certificate
Model Number: PG-ET
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: woodencase
Delivery Time: 15 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Detailed Product Description
Standard: IEC60335-2-7, IEC60335-2-11 Application: For Testing Washing Machine, Tumble Dryer, Centrifugal Dehydrator
Material: Aluminum Alloy Control System: PLC+7 Inch Touch Screen
Sample Clamping Mode: Vacuum Suction Cup Working Power: 220V/50Hz
High Light:

Door Interlock Endurance Testing Machine

,

IEC60335 Endurance Testing Machine

,

Door Interlock Endurance Test Machine

IEC60335-2-7 PLC Control Door and Interlock Endurance Testing Equipment for Washing Machine



1. Introduction

Washing machine door endurance test machine can meet the requirement of IEC60335-2-7 clauses 18.101 and 22.104, IEC60335-2-11 clause 20.101 and IEC60335-2-4 clause 18, it is a special test equipment applied to life test of lid or door interlock of various washing machines and tensile force test when the interlock device acts to lock the door. The washing machine door endurance test machine can be set flexibly as per different washing machine. The test machine adopts PLC controller and touch screen, and the motor drives the transmission rod to reciprocate the switch movement. It can independently realize the reciprocating action of "opening and closing" the lid and door of washing machine. The rack is made by high grade aluminium alloy, and the door is fixed by a vacuum suction cup structure, which is easy to operate and easy to control.



2. Test principle:

Use the edited program to control the power-on and power-off of the interlocking device, drive the mechanical arm through the motor, and drive the door or lid that is sucked by the vacuum suction cup to reciprocate opening and closing at a certain speed, so as to verify the reliability of the interlocking device. A force sensor is installed on the mechanical arm, which forms a closed-loop control with the servo motor, and can precisely control the closing force value.



3. Parameter

Test stations 2, can independent test the drum washing machine and pulsator washing machine
Control system PLC+7 inch touch screen
Drive mode Servo motor
Sample clamping mode vacuum suction cup, drive by pneumatic (user prepare the air compressor 0.5-0.7Mpa)
Speed of opening 0-3600/s (1.5m/s) presettable
Opening angle 0-1300 presettable
Test cycles 0-999999 presettable
Opening and closing force 0-200N presettable (The opening force is only for the tension test when the interlock device acts to lock the door)
Supply mains 0-250V adjustable
Test sample and its limitation

Electric tumble dryer, electric washing machine (includes drum washing machine with single-phase voltage≤250V, others ≤480V)

Centrifugal Dehydrator (load capacity ≤10KG, roller linear speed≤50m/s, single phase voltage≤250V, others ≤480V)

Equipment structure

a. Consisted by electrical control cabinet (built-in Load voltage regulator), test racks equip with mechanical arm

b. the drum washing machine and pulsator washing machine can be placed in 2 independent test racks, the test can be performed independently.

c. Dimension: L2500mm*W1300mm*H1300mm

b. Weight: 180kg

Working condition

a. power supply: AC220V±10%/50Hz, 6KW

b. Working conditions: 5-40℃ (A.T.), 20-80% R.H., 80-106kpa

Protection device Leakage protection, over-load protection, short-circuit protection
