IEC60695-2-10 Flammability Testing Needle Flame Test Apparatus

IEC60695-2-10 Flammability Testing Needle Flame Test Apparatus
IEC60695-2-10 Flammability Testing Needle Flame Test Apparatus

Large Image :  IEC60695-2-10 Flammability Testing Needle Flame Test Apparatus

Product Details:
Place of Origin: China
Brand Name: PEGO Group
Certification: Third-Lab Calibration Certificate
Model Number: NF-1H
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: woodencase
Delivery Time: 7 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Detailed Product Description
Standard: IEC60695-11-5 Control Way: Touch Screen+PLC
Burning Angle: 45 Degrees Accessories: Needle Burner, Copper Block, Wrapping Tissue, Wooden Board
Warranty: 12 Months Working Power: 220V/50Hz
Highlight:

Needle Flame Test Apparatus

,

IEC60695-2-10 Flammability Testing Apparatus

IEC60695-2-10 Flammability Testing Needle Flame Test Apparatus

1. Introduction

The needle flame test apparatus is designed according to the requirements of IEC 60695-11-5, GB/T5169.5, Section 13.3.1 of IEC60598-1, Appendix G.2.1 and Section S.1 of IEC62368-1, and Section 30.2.4 of IEC60335-1. It is widely used in material testing of electrical and electronic products and equipment components and parts such as lamps, household appliances, IT/AV equipment, and electrical accessories, and is also suitable for the evaluation of solid insulating materials or other combustible materials. The equipment is used to simulate the effect of a small flame caused by a faulty adjustment, and uses simulation technology to assess the fire hazard. The equipment is equipped with a 7-inch color touch screen, PLC, drive motor, flame calibration system, ignition gun, pine board, trickle paper, and a four-button remote control.





2. Standard

- IEC60695-11-5 Fire hazard testing - Part 11-5: Test flames - Needle-flame test method - apparatus, confirmatory test arrangement and guidance

- IEC60598-1 Luminaires - Part 1: General requirements and tests clause 13.3.1

- IEC60238-1 Audio/video, information and communication technology equipment - Part 1: Safety requirements Annex G.2.1, clause S.1

- IEC60335-1 Household and similar electrical appliance - Safety - Part 1: General requirements clause 30.2.4





3. Parameters

Power supply AC 220V/50Hz
Control system 7-inch color touch Screen + PLC
Burner

Inner diameter: Φ 0.5mm ± 0.1mm

Outer diameter: ≤Φ 0.9mm

Length: ≥35mm,

Material: stainless steel

Chamber volume ≥ 0.5m3 , matte black background, illuminance ≤ 20Lux, built in exhaust fan, exhaust hole: Φ100mm
Temperature sensor Copper with Φ4±0.01mm and 0.58±0.1g weight,
Thermocouple

Omega,

Diameter: Φ0.5mm K type,

Material: K type

Burner angle 450 or 900, auto switch
Ignition way Manual
Gas 95% butane gas or propane gas (prepare by user)
Flame height 12mm ± 1mm (adjustable), stainless steel
Timer

Integrated in PLC

Accuracy: ±0.1s

Ignition layer White pine board with thickness 10mm, and cover with wrapping tissue 12g/m2 ~30g/m2
Drive Mode Auto, with 4-button remote control
Dimension 1100mm*630mm*1300mm





4. Figures

 IEC60695-2-10 Flammability Testing Needle Flame Test Apparatus 0
