PLC Control IEC60112 Standard Tracking Index Test Apparatus with 220V/50Hz Power and 12 Months Warranty

Large Image : PLC Control IEC60112 Standard Tracking Index Test Apparatus with 220V/50Hz Power and 12 Months Warranty

Product Details:

Place of Origin:	China
Brand Name:	PEGO Group
Certification:	Third-Lab Calibration Certificate
Model Number:	TI-1H

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	woodencase
Delivery Time:	15 working days
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	50 sets/month

Contact Now

Detailed Product Description

Standard:	IEC60112	Control System:	PLC
Configuration:	Platinum Electrodes, Dripping System, Glassware	Working Power:	220V/50Hz
Warrranty:	12 Months	Application:	Flammability Testing
Highlight:	220V/50Hz Power Tracking Index Test Apparatus , 12 Months Warranty Flammability Testing Equipment , 7-inch Color Touch Screen Electrical Safety Tester

PLC Type IEC60112 Flammability Testing Tracking Index Test Apparatus

Introduction

The tracking index test apparatus is designed according to multiple international standards including IEC 60112, GB/T 4207, and various clauses from IEC62368-1, IEC60598-1, IEC60601-1, IEC60335-1, IEC61010-1, IEC60884-1, and BS1363-1. This equipment is essential for material testing across various electrical products such as lamps, household appliances, IT/AV equipment, and electrical accessories.

The apparatus measures the tracking resistance index to evaluate material performance in humid environments. Key features include a 7-inch color touch screen, PLC control system, imported medical-grade titration pump, high-power voltage regulator, and pure platinum electrodes.

Compliance Standards

IEC60112: Method for determining proof and comparative tracking indices
IEC60598-1: Luminaires - General requirements (clause 13.4)
IEC62368-1: AV/ICT equipment safety (clause 5.4.3.3)
IEC60601-1: Medical equipment safety (clause 8.9.1.7)
IEC60335-1: Household appliances safety (clause 29)
IEC61010-1: Medical equipment safety (clause 6.7.1.3)
IEC60884-1: Plugs and sockets (clause 28.2)
BS1363-1: 13A plugs specification (clause 8.2 Annex C)

Technical Parameters

Parameter	Specification
Control system	7-inch color touch screen + PLC
Electrode material	Platinum (Pt) purity ≥ 99%
Electrode size	(2mm±0.1mm)(5mm±0.1mm)(40mm±5mm), length≥12mm, angle: 30°±2°
Electrode distance	4.0mm±0.1mm, angle: 60°±5°
Electrode pressure	1.00±0.05N
Electrode voltage	100~600V
Height of drops	35mm±5mm adjustable
Size of drops	20 drops: 0.380g~0.480g, 50 drops: 0.997g~1.147g
Drop interval	30s±5s, 50 drops: 24.5min±2min
Test solutions resistance	Solution A: 0.1%NH4Cl, 3.95±0.05Ωm; Solution B: 1.98±0.05Ωm
Number of drops	0~9999 (presettable)
Test wind speed	0.2m/s
Short circuit current drop	1.0A±0.1A drop 10%
Leakage indicator	0.50A±10%, 2.00s±10%
Standards compliance	IEC60112, UL746A, ASTM D 3638-92, DIN 53480
Accessories	Dripping system, glassware, block gauge, electrodes
Dimensions	800mm (W) * 500mm (D) * 970mm (H)
Power requirements	220V/50Hz, 1KVA

Understanding PTI (Proof Tracking Index)

PTI represents the voltage value at which a material can withstand 50 drops of electrolyte without electrical tracking, measured in volts.

Understanding CTI (Comparative Tracking Index)

CTI indicates the highest voltage value where a material's surface resists electrical tracking after 50 electrolyte drops, measured in volts.

Test Solutions

Solution A is standard: 0.1% by mass of analytical reagent grade anhydrous ammonium chloride (NH4Cl, purity ≥99.8%) dissolved in de-ionized water to achieve resistivity of (3.95±0.05) Ωm at (23±1)℃.

Product Image
