UL858 Standard Articulated Probe with Stainless Steel Finger for Accessibility Test and Jointed Test Probe

UL858 Standard Articulated Probe with Stainless Steel Finger for Accessibility Test and Jointed Test Probe
UL858 Standard Articulated Probe with Stainless Steel Finger for Accessibility Test and Jointed Test Probe
video play

Large Image :  UL858 Standard Articulated Probe with Stainless Steel Finger for Accessibility Test and Jointed Test Probe

Product Details:
Place of Origin: China
Brand Name: PEGO GROUP
Certification: Third-lab Calibration Certificate
Model Number: PG-PA100A
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: carton box
Delivery Time: 15 working days
Payment Terms: T/T,Western Union,MoneyGram
Contact Now
Detailed Product Description
Standard: UL858 Figure 6.1, IEC62368-1 Figure V.1, UL507 Figure 6.5 (PA100A) Name: Jointed Test Probe, Articulated Probe With Web Stop
Application: Accessibility Test Material: Nylon And Stainless Steel
Shippment: By Express Warranty: 12 Months
Highlight:

UL858 Standard Test Finger Probe

,

Stainless Steel Finger Articulated Probe

,

Accessibility Test Jointed Test Probe

UL858 Articulate Test Finger Probe with Web Stop
This UL Articulated Finger Probe with Web Stop is designed for comprehensive accessibility testing, featuring a palm simulator and restricted joint movement that accurately simulates human finger movement.
Standards Compliance
Conforms to UL858 figure 6.1, IEC62368-1 figure V.1, UL507 figure 6.5 (PA100A), UL1017 figure 2, UL1062 figure 1.2, UL1310 figure 14.2, UL982 figure 7.1, UL474 figure 5.1, UL6500 figure 14, UL60065 figure 14, UL1082 figure 7.2 and UL1278 figure 8.3.
Product Description
The articulated probe with web stop is manufactured from durable nylon with stainless steel finger components. This professional testing instrument simulates human finger movement through its palm simulator design and restricted joint mechanism. Bell-Core accessory is available for enhanced testing capabilities.
Specifications
Parameter Value
Test Finger Length 234mm
Bending Part Length 30mm / 60mm / 100mm
Reference Standards UL507, UL982, UL1278, UL1062, UL1310, UL474, UL60065
Calibration Report
Nominal Value Measured Value Expanded Uncertainty Conclusion
234 mm 233.98 mm 0.05 mm P
154 mm 154.07 mm 0.05 mm P
136 mm 136.14 mm 0.05 mm P
100 mm 100.30 mm 0.05 mm P
96 mm 96.09 mm 0.05 mm P
90 mm 90.21 mm 0.05 mm P
60 mm 60.08 mm 0.03 mm P
30 mm 30.05 mm 0.03 mm P
UL858 Standard Articulated Probe with Stainless Steel Finger for Accessibility Test and Jointed Test Probe 0
Competitive Advantages
Professional Expertise: Specialized in electrical lab testing equipment with focus on superior pricing, quality, and service.
Customized Solutions: Design and development of new equipment according to specific customer requirements.
Quality Assurance: 12-month warranty with 100% pre-delivery testing and ISO17025 certified third-party calibration.
Technical Support: 24-hour technical assistance via email with professional consulting services.
Efficient Delivery: Just-in-time delivery with cost-effective transportation solutions.
Responsive Service: Guaranteed response to customer inquiries within 24 hours.
