LCD 1.2μS 50μS 10KV Impulse Withstand Voltage Generator

LCD 1.2μS 50μS 10KV Impulse Withstand Voltage Generator
LCD 1.2μS 50μS 10KV Impulse Withstand Voltage Generator

Large Image :  LCD 1.2μS 50μS 10KV Impulse Withstand Voltage Generator

Product Details:
Place of Origin: China
Brand Name: PEGO GROUP
Certification: Third-Lab Calibration Certficate
Model Number: LSG-255
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD5000~USD6500
Packaging Details: woodencase
Delivery Time: 15 working days
Payment Terms: T/T, Western Union, MoneyGram
Detailed Product Description
Standard: IEC 60335, IEC60950, IEC60060, IEC1036 Control Unit: LCD Touch Screen
Test Voltage: 10KV, 12KV, 15KV (option) Waveform: 1.2μs/50μs
Working Power: AC220V, 50Hz/60Hz Warranty: 12 Months
High Light:

10KV Impulse Withstand Voltage Generator


50μs Impulse Withstand Voltage Generator


1.2μS Voltage Wave Tester

10KV Impulse Withstand Voltage Generator 1.2μs/50μs Voltage Wave


1. Introduction

The impulse withstand voltage generator is a voltage wave tester with a waveform of 1.2μs/50μs. The frontier time is 1.2μs and the half-peak time is 50μs. It conforms to the standards of IEC 60335 and IEC60950 standard, GB/T 17215-1998, GB 7251.1-1997 8.2, IEC60060, IEC1036: 1996, GB/T 16916.1, GB/T 16917.1, GB/T 14048.1-2001 and etc.. The equipment is used to detect the ability of watt-hour meters, low-voltage electrical components to withstand transient over-voltages, and the Electrical clearance and creepage distance. The test voltage is up to 10KV/12KV/15KV.


2. Features:

1) 7 inch LCD touch screen with multifunction, easy to operation and update software

2) Built in over-voltage, over-current, short circuit protection

3) Voltage error and no output warning

4) Chinese and English software available


3. Technical Parameters:

Open output voltage 12KV (max)±5%
Frontier time 1.2μs ±30%
Half-value time 50μs ±20%
Output polarity positive, negative, positive/negative automatically
Output impedance (optional) 2Ω,500Ω±10%
Test times 1~9999 times
Surge interval 3~999s
Working environment 15℃~35℃ (temperature), 10%~75% (humidity)
Working power 220V±10% AC, 50/60Hz
Dimension 470mm*260mm*500mm (W*H*D)
Weight 35KG


4. Picture

 LCD 1.2μS 50μS 10KV Impulse Withstand Voltage Generator 0



1). What is the warranty period of the equipment?
Answer: the equipment warranty is 12 months upon you receipt of the equipment


2). Can you provide third-lab calibration certificate?
Answer: Yes, the equipment can send to the third-labs authorized by ISO17025 and get the calibration certificate, but the buyer should undertake the charges.


3). Does this equipment has English operation interface?
Answer: of course, yes, the operation interface has English instruction.


4). What is the working power of the equipment?
Answer: AC 220V±10%, 50Hz/60Hz
