IEC60320-1 Compliant Lateral Pull Test Apparatus with PLC+5 Inch Touch Screen Control for 6N/35N/50N Pull Force Testing

IEC60320-1 Compliant Lateral Pull Test Apparatus with PLC+5 Inch Touch Screen Control for 6N/35N/50N Pull Force Testing
IEC60320-1 Compliant Lateral Pull Test Apparatus with PLC+5 Inch Touch Screen Control for 6N/35N/50N Pull Force Testing

Large Image :  IEC60320-1 Compliant Lateral Pull Test Apparatus with PLC+5 Inch Touch Screen Control for 6N/35N/50N Pull Force Testing

Product Details:
Place of Origin: China
Brand Name: Pego Electronics
Certification: Third-Lab cablibration certificate
Model Number: PG-LTP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: woodencase
Delivery Time: 20 working days
Payment Terms: T/T,PayPal
Supply Ability: 50 sets/months
Contact Now
Detailed Product Description
Normative Reference: IEC60320-1 Clause Clause 23.3 And Figure 8 Application: For Verifying The Mechanical Strength Of Appliance Couplers
Working Power: AC 220V/50Hz Pull Force: 6N, 35N, 50N
Control Units: PLC+5 Inch Touch Screen
Highlight:

PLC+5 Inch Touch Screen Control Lateral Pull Test Apparatus

,

6N/35N/50N Pull Force Appliance Couplers Testing Equipment

,

AC 220V/50Hz Power IEC60320-1 Test Equipment

Lateral Pull Test Apparatus for Testing Appliance Couplers as per IEC60320-1
Appliance Couplers Lateral Pull Test Apparatus
The appliance couplers lateral pull test apparatus is designed to meet the test requirements of IEC60320-1 clause 23.3 and figure 8 to verify if the contact of connectors and appliance outlets have sufficient mechanical strength.
A lateral pull force in parallel with the engagement face is applied to the cable of the connector/plug connector in four directions in steps of 90°±5°. A pull force is applied 50 times in each direction to the cord for 1s ±0.5s. After the test, the connector/appliance outlet shall show no damage.
Specification
Controller PLC+ 5 inch LCD touch screen
Drive mode Gear motor
Pull force 6N*1, 35N*1, 50N*1
Working power AC 220V/50Hz, 200W (max)
Dimension L350mm*W530mm*H850mm
